Motorola APX 4000 User Manual

A
B
C
2 Rotate and lift the connector cover to disengage it
from the radio.
3 To attach the accessory connector cover, insert
the hooked end of the cover into the slot above
the connector.
4 Press downward on the cover’s top to seat it in the
slot.
5 Once in place, tighten by rotating the thumbscrew
clockwise by hand.
Attaching the Belt Clip
1 Align the grooves of the belt clip with those of the
radio and push down until you hear a click.
See the following picture for MFK radio.
See the following picture for two knobs
radio.
Preparing Your Radio for Use
25
English

Motorola APX 4000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Frequency Range	VHF: 136-174 MHz, UHF: 380-470 MHz, 450-520 MHz
Power Output	VHF: 1-5W; UHF: 1-4W
Digital Protocol	APCO P25
Dimensions	5.2 x 2.4 x 1.5 inches (without battery)
