Motorola APX 4000 User Manual

Select
Disabled
Select-disabled radios cannot change
channels while dynamically regrouped.
The dispatcher has forced the radio to
remain on the dynamic-regrouping
channel.
The Scan or Private Call feature cannot be selected
while your radio is Select Disabled.
Dynamic Zone Programming (DZP)
Note: Your radio must be preprogrammed to allow
you to use this feature. This feature works on the
condition at least one zone in the radio must be a
non-dynamic zone.
This feature provides one or more Dynamic Zones to
store the frequent used channels be it conventional or
trunking. These dynamic channels are saved from
pre-existing (non-dynamic) channels in the radio. This
saves the time and effort from the regular navigation
around the working zones and channels. User can
also delete or update the list in the Dynamic Zone.
Entering the Dynamic Zone to Select a Dynamic
Channel
1
or to Zone then press the Menu Select button
directly below Zone.
The display shows the Zone screen.
2
or to <# Dynamic Zone Channels>.
[2]
3 Perform one of the following actions:
•
Press the Menu Select button below Sel to
select.
•
Press the Menu Select button below Exit to
exit.
If you have selected one of the Dynamic Zone
Channels list, the display returns to Home screen
with the selected <# Dynamic Zone Channels>
shown on the screen.
[2]
If you have selected Exit without selecting any
Dynamic Zone Channels list, the display returns to
Home screen without any changes.
2
# indicates number of the channel on the 16-Position Switch which are numbered from 1 to 16.
Advanced Features
78
English

Motorola APX 4000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Frequency Range	VHF: 136-174 MHz, UHF: 380-470 MHz, 450-520 MHz
Power Output	VHF: 1-5W; UHF: 1-4W
Digital Protocol	APCO P25
Dimensions	5.2 x 2.4 x 1.5 inches (without battery)
