Apex Classic Setup and Programming Guide v2.2 Page 102
Screens from the AquaController Apex Display and Web Interface (see the section
titled Virtual Outlets for more information). The same ATO program is listed
below with the use of Virtual Outlets for the 2 switch inputs.
Assign and create the following outlets using the instructions in earlier sections of
this manual.
ATO Automatic Top Off, this outlet is where the top-off pump is
connected.
Sump_High create as a Virtual Outlet to indicate the state of the
Sump_High float switch.
Sump_Low create as a Virtual Outlet to indicate the state of the Sump_Low
float switch.
Outlet Programs
Sump_Low <Virtual Outlet>
If Switch1 CLOSED Then ON
If Switch1 OPEN Then OFF
Sump_High <Virtual Outlet>
If Switch2 CLOSED Then ON
If Switch2 OPEN Then OFF
ATO <Real Outlet>
Fallback OFF
If Outlet Sump_Low = ON Then ON
If Outlet Sump_High = ON Then OFF
SndAlm <System Outlet>
If Outlet Sump_High = ON Then ON
… other alarm commands
EmailAlm <System Outlet>
If Outlet Sump_High = ON Then ON
… other alarm commands
You can see that assigning Virtual Outlets to the Switches makes reading and
understanding what is going on in the outlet programs much easier.
KALKWASSER CONTROL
