NETGEAR M4350 Series User Manual

Table 1. LEDs of model M4350-8X8FV (Continued)
DescriptionLED
The Stack LED contains segments that can indicate the stack unit number of the
switch:
Solid green indicating a number: The switch is a member of a stack. The LED
displays the stack unit number.
Solid green indicating E: The switch functions in ECO mode with all port LEDs
turned off.
Off: The switch is not a member of a stack.
STACK ID LED
Port LEDs, Front Panel
Left LED, speed, activity, and link status:
Off: No link is established on the port.
Solid green: The port established a 10G link.
Blinking green: The port is transmitting or receiving packets at 10G.
Solid yellow: The port established a 5G, 2.5G, 1G, or 100M link.
Blinking yellow: The port is transmitting or receiving packets at 5G, 2.5G, 1G,
or 100M.
Port LEDs for multispeed
Ethernet ports numbered 1
through 8
Off: No SFP module link is established on the fiber port.
Solid green: The fiber port established a 10G link.
Blinking green: The fiber port is transmitting or receiving packets at 10G.
Solid yellow: The fiber port established a 1G link.
Blinking yellow: The fiber port is transmitting or receiving packets at 1G.
Port LEDs for SFP+ ports
numbered 9 through 16
Port LEDs, Back Panel
Left LED, speed status:
Solid green: The port established a 1G link.
Solid yellow: The port established a 100 M link.
Off: No link is established on the port.
OOB Ethernet port LEDs
Right LED, activity and link status:
Solid green: The port established a link.
Blinking green: The port is transmitting or receiving packets.
Off: No link is established on the port.
Model M4350-12X12F (SKU XSM4324)
This section describes the switch hardware features for model M4350-12X12F (SKU
XSM4324). This half-width model provides a switching fabric of 480 Gbps and supports
the following port configurations:
•
Twelve multispeed Ethernet RJ-45 ports that support 10 Gbps, 5 Gbps, 2.5 Gbps, 1
Gbps, and 100 Mbps
•
Twelve SFP+ fiber uplink ports that support 10 Gbps or 1 Gbps transceiver modules
Hardware Installation Guide16Hardware Overview
