7-MAINTENANCE
TwineWrapper[25802796]
Twinetension
Adjustthefourcompressionsprings(1)equallytoanef-
fectivespringlengthA=50mm(2.0in)forpolypropylene
750m/kgtwine.Decreasethetwinetensionwiththicker
twine,increasewiththinnertwine.
Correcttwineclamptensionshouldresultinapullof20-
50N(4.5-11.2lb)requiredtopullthetwinefromtheend
ofthetwinetubeswith:
•
Thespreaderhooksinthemiddleposition.
•
Pullingthetwinethroughthetwinefeedopening,
fromthebalechamber(undertheraisedtailgate).
NOTE:Thetwinetensionistoohighwhendifcultyisex-
periencedinstartingthetwinetowraparoundthebale.
Itmaybenecessarytoreadjustthetensionwhenchang-
ingtwine,suchasfromplastictosisal.
Incaseoftroublesometwinestarting,alwayscheckfor
correcttwineroutingrst.
NOTE:Thetwinetensionistoolightwhenthetwinestarts
slippingoverthepatternpulley.
ZIL10FCRB793AAA1
TwineInstallation[25802849]
Twinefeedrolls
Adjustthetensionspringbolts(1)toalength(fromnutto
eye)of:
X=62-64mm(2.4-2.5in)
Excessivetensiononthefeedrollsmaycrushthetwine
andcausestiffrotationofthefeedrolls.
Insufcienttensiononthefeedrollswillmaketherollsslip
onthetwineatwrapcyclestart.Thiscouldleadtotwine
breakage.
ZIL10FCRB794AAA1
7-10
