4-OPERATINGINSTRUCTIONS
Hydraulicconnections[25663731]
Hydraulicsystem
WARNING
Pressurizedhydraulicuidcanpenetratethe
skinandcausesevereinjuries.
Tightenalloftheconnectionsbeforestarting
theengine.Ifhydraulicuidhaspenetrated
theskin,seekmedicalassistanceimmedi-
ately.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0117A
1.Thesupplyhoses(3)onthebalertooperatethetail-
gateandthehydraulicpickuplifthaveatractor‐end
malecoupler(1)complyingwithFIEIstandarddi-
mensions.
Anadaptor(2)joinsthehosetothecoupler.This
couplerwilltmostofourtractors,aswellasthe
majorityofotherbrandsoftractors.Ifthisisnot
thecase,obtaintheappropriatequick‐couplerfor
thetractorthatwillbeused,andpossiblyanother
adaptorthatwilltthehose(3).
InstallthecouplersusingTeontapeorasimilar
materialonthethreadstopreventjointleakage.
ZIL10FCRB143AAA1
Couplersareprovidedwithacoloredcapforsuggestedusage:
Color
Function
ControlValve
GreenPick-up(wheretted)Singleacting.
IfusingDoubleactingvalve-connectatliftportto
operateanduseoattolowerandrelievepressure
BlueTailgate
Singleacting.
IfusingDoubleactingvalve-connectatliftportto
operateanduseoattolowerandrelievepressure
Black,Red
Rotorreverser(wheretted)Singleacting.
IfusingDoubleactingvalve-connectatliftportto
operateanduseoattolowerandrelievepressure
ATTENTION:Checkwithyourtractordealertobecertain
yourtractorhydraulicuidiscompatiblewiththebaleroil.
Ifthereisanyquestionabouttheoilcompatibility,purge
alloilfromthebalerhydraulicsystem,otherwisedamage
tothetractorhydraulicsystemcouldresult.
NOTE:Thetailgateandrotorreversersupplyhosesand
cylinderscontainapproximately1lofoil.
Keepthehoseendsandttingsfreefromcontamination
duringinstallationandhookup,ordamagetothetractor
and/orbalerhydraulicsystemmayresult.
4-13
