6-WORKINGOPERATIONS
Pickup[32466429]
Standardpickup
Windguard,Figure1.
Thewindguard(6)ismadequick‐attachbymeansofa
spring‐loadedplate(5),tomakeclearingofblockages
moreeasy.
Furthermore,thewindguardcanbelocatedin2different
positions:
•
Lowerholeforshortcrop,smallwindrows.
•
Upperholeforbigvoluminouswindrows.
ZIL10FCRB752AAA1
Rollerwindguard(wheretted)
Arollerwindguardisavailablewhichaidscropowinto
therotor.
Thewindguardcanbelocatedin2differentpositions:
•
Lowerholeforshortcrop,smallwindrows.
•
Upperholeforbigvoluminouswindrows.
ZIL10FCRB182AAA2
Pickupheight
Onmachinesttedwiththeaccessorypickupgauge
wheels,adjustthegaugewheelswithbolts(2)toobtaina
minimumpickuptinetogroundclearanceof30mm(1.2
in).Increasethepickupheightinstonyoruneveneld
conditions.
Adjustsuspensionchain(1)withalittleslack.
Inextremelyroughorhighstubbleconditions,itiseven
recommendedtoworkwiththepickupwheelsoffthe
ground.Liftthepickupcompletelyandadjustthepickup
heightasexplainedbelow.
Onmachineswithoutgaugewheels,adjustthepickup
heightwithchain(1).Tochangethepickupheight,grab
thehandle(3)(Figure1)andliftthepickupmanuallyto
relocatethechaininthenotch(1),Figure1.
Onmachinesequippedwiththepickuphydraulicliftfea-
ture,thepickupcanbeliftedwiththetractorhydraulicsto
adjustchain(1).Forroadtransport,liftthepickupcom-
pletelyandengagethechainashighaspossible.Then
lowerthepickuphydraulicallyandplacethevalveleverin
theneutralposition.
