7-MAINTENANCE
Withthetailgateopen,andthedensityindicator(1)fully
raisedup,adjusttherubberstop(3)toaclearanceof:
(2)=0-2mm(0.0-0.1in)betweenthedensityindicator
andtherubberstop.
BaleLoaderSensorAdjustment[25803376]
Fullbalealarmsensor
Thefullbalealarmsensor(1)makespartoftheelectric
controlboxsystem,suppliedondemand.
Adjustthemagnet(4)withscrews(2)ontheleftdensity
indicatorforaclearanceof(3)=maximum5mm(0.2in)
whenthemagnetpassesinfrontofthesensor.
ZIL10FCRB798AAA1
Baleejection[25803419]
Balekicker
Dependingonlocalsalespolicy,thebalekickerwillbet-
tedstandardonthemachine,orofferedasanaccessory.
Thebalekickerforceisadjustabletosuitbaleweightand
eldconditions.
1.Withthetailgateopen,therearbarofthekickeris
setataheight(1)=620-640mm(24.4-25.2in)
withthenutsandcounternuts(2).Thisadjustment
mustnotbechanged.
ZIL10FCRB799AAA1
2.Alsowiththetailgateopen,thespringissetata
tension(T)=448-452mm(17.6-17.8in)with
locknut(3).
Inanycase,whenadjustingthebalekickerspringstosuit
operatingconditions,makesurethat:
•
Thebalekickerwillalwayscontactthegroundbe-
forethespringsarebottomingout,ifcoilboundtoo
tight..
•
Thebalekickerwillbounceexcessivelyduringroad
transport,springstoolight.
ZIL10FCRB816AAA2
7-20
