1-GENERALINFORMATION
Jackstand[25765689]
Windingthejackcrank(5)willraiseorlowerthebaler
tonguetoattach/detachthebalerfromthetractor.The
completejackstand(6)canbemoveddowntothestorage
position,andmoveduptothetransportposition.Grab
thejackatthecrank(5)and/orthegrabhandle(7)Refer
Figure,3.
ZIL10FCRB110AAA1
Thespring‐loadedjackstandlatch(4)hasthreepositions
tobeused:
•
Latch(4)engagedinnotch(3)securesthejack
standineitherstorageortransportposition.Make
surethelatchissecurelyengagedinnotch(3)at
alltimesineitherthetransportorstorageposition
ofthejack.Inthetransportposition,windthecrank
(5)toliftthejackfullyup.
•
Latch(4)disengagedandridingalongtheedge(2)
allowsthejackstandtobemovedupordown.It
snapsengagedautomaticallywhenthedesiredpo-
sitionisreached.
•
Notch(1)allowsthelatch(4)tobemechanically
lockedouttemporarilyduringthemanipulation
process,orpermanentlyshouldspecialsituations
requireso.
WARNING
Crushinghazard!
Equipmentcouldfallifnotproperlysup-
ported.Positionsuitablejackstandsunder
thefeederhousingandsecureinplacebefore
servicing.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0008B
ATTENTION:Becautiouswhenoperatingthejackstand.
Thereisriskofinjurybypinchingorshearingpoints.Grab
thejackcrankwithbothhandsasillustratedtoliftand
lowerthejackstand.
ZIL10FCRB144AAA2
ZIL10FCRB103AAA3
