3-CONTROLS/INSTRUMENTS
3-CONTROLS/INSTRUMENTS
MonitorOperation
BalerOperatorControlsControlbox(Optional)[31613027]
Installthecontrolboxonasupportinsidethetractorcabor
onthefenderinacomfortablereacheldfromthetractor
seat.
ZIL10FCRB750AAA1
Connectthepowercabletoa12Vpowersourceinthe
tractorcab,capableofsupplying15Apeakload,ordi-
rectlytothebattery.
ATTENTION:Connecttheredwiretothepluspoleofthe
battery.Ifnot,theactuatorwillextendautomaticallyto
fullextendpositionwheneverthecontrolboxisturnedon.
Thiswillresultinmalfunctionofthetwinewrapper.
1.Controlbox.
2.Actuator.
3.Magneticfullbaleswitch.
4.12Vpowersource.
ZIL10FCRB751AAA2
Thesystemprovidesthefollowingfeaturestotheopera-
tor:
•
Manualelectriccontrolovertwinewrapstart
•
Audiblealarmatfullbaledensity
•
Acousticsignalwhenthetailgatelatches
Theelectriccontrolboxsystemconsistsofthefollowing
components:
3-1
