Chapter 3 Individual Operations
137
Individual
Operations
Motorized Unit that Save/Loads the State with MODE Function
Setting items Stored Information
CONDEN. Condenser module of the motorized universal condenser in the optical path
FL TURRET Filter cube of the motorized epi-fluorescence cube turret in the optical path
FL [SHUTTER] Opening/closing of the motorized epi-fluorescence cube turret built-in shutter
FL 2nd Filter cube of the motorized epi-fluorescence cube turret on the 2nd layer that is brought in the
optical path
FL2 [SHUTTER] Opening/closing of the built-in shutter of the motorized epi-fluorescence cube turret on the 2nd layer
EX WHEEL Excitation filter of the motorized excitation filter wheel in the optical path
BA WHEEL Barrier filter of the motorized barrier filter wheel in the optical path
PATH Optical path in the motorized quadrocular tilting tube
Z Position of the elevating section
*1
EPI SHUTTER Opening/closing of the EPI motorized shutter
DIA SHUTTER Opening/closing of the DIA motorized shutter
LAMP ADJ. Brightness of the dia-illumination lamp
LAMP Turns the dia-illumination lamp on or off.
INTSL [SHUTTER] Opening/closing of the motorized HG precentered fiber illuminator's built-in shutter
INTSL ND filters in the motorized HG precentered fiber illuminator
A. STOP Aperture diaphragm diameter of the motorized universal condenser
F. STOP Field diaphragm diameter
ZOOM Zoom magnification of the motorized DSC zooming port
ND WHEEL ND filter transmittance of the motorized ND filter wheel
*1 The elevating section of the Ni-E microscope will be excluded from the MODE setting automatically when the
microscope is powered ON again to prevent a specimen from contacting the objective.
