Nordson DuraBlue D4L User Manual

Parts
7-11
Part 1073401_07
E 2021 Nordson Corporation
Item Part Description Quantity Note
1 1056358
MOTOR,
1
/
6
HP, WITH PIGTAIL, 55.3 RPM
1
NS 1056056 S CAPACITOR, 18μ F, 240 VAC 1 A
1 1031212
MOTOR,
1
/
4
HP, WITH PIGTAIL, 89 RPM, 240V
1
NS 7403190 S CAPACITOR, 30μF, 450V, 240 VAC 1 A
NS 7403188 S BRACKET,CAPACITOR,D4,DURABLUE 1 B
NS 7403129 S BRACKET,CAPACITOR,D10/16,DURABLUE 1 C
1 7404319
MOTOR,1/4 HP, WITH PIGTAIL,89 RPM,120V
1
NS 7403190 S CAPACITOR, 30μF,450V,240 VAC 1 A
NS 7403188 S BRACKET,CAPACITOR,D4,DURABLUE 1 B
NS 7403129 S BRACKET,CAPACITOR,D10/16,DURABLUE 1 C
1 7404319
MOTOR,1/4 HP, WITH PIGTAIL,89 RPM,120V
1
NS 7403190 S CAPACITOR, 30μF,450V,240 VAC 1 A
NS 7403188 S BRACKET,CAPACITOR,D4,DURABLUE 1 B
NS 7403129 S BRACKET,CAPACITOR,D10/16,DURABLUE 1 C
1 7404320
MOTOR,1/4 HP, WITH PIGTAIL,131 RPM,120V
1
NS 7403190 S CAPACITOR, 30μF,450V,240 VAC 1 A
NS 7403188
BRACKET,CAPACITOR,D4,DURABLUE
1 B
NS 7403129
BRACKET,CAPACITOR,D10/16,DURABLUE
1 C
NOTE A: For the location of the capacitor, see Figure 7‐2.
B: Used for 4L DuraBlue melter. If B is used, C is not necessary.
C: Used for 10/16L DuraBlue melter. If C is used, B is not necessary.
NS: Not Shown
