Read Status Smoke Detector
Enter an address to view its attributes (the cursor will be in the underlined section).
NEXT POINT/PREVIOUS POINT - Press to view next or previous point.
ACCEPT - Press to accept the displayed point for further viewing.
Pressing the ACCEPT soft key on the Point Select Screen will display the information that corre-
sponds to the chosen point. Each point type has its own screen.
3.2 Smoke Detector
When a detector address is entered into the Point Select Screen and the ACCEPT soft key is
pressed, the following screen will display if the detector is a smoke detector.
Figure 3.2 Smoke Detector Screen - Read Status
Display
Lines 1- 4 - This could display any current event message, or, as in this example, the System Nor-
mal message.
Line 5 - This line contains the screen title and the address of the point being read.
Special Function Zone NxxxZFxx ZF=Special Function Zone, x=Special Function Zone number
(00, 01 - 07, 09 - 22)
Trouble Zone NxxxZTyyy ZT=Trouble Zone, yyy=Trouble Zone number (1-100)
DAA Speaker CKT NxxxAyySn N indicates Node number, xxx=DVC/DVC-EM Node number, A
indicates DAA-5025 or DAA-5070 Audio Amplifier, yy=DAA
address (01 through 32), S indicates Speaker circuit, n =
Speaker circuit number (1-4).
* The Nxxx preface to all the above address formats refers to the node number, where N = node, xxx = the network node number.
Type Address Format*
Table 3.1 Address Formats (2 of 2)
NOTE: The first four lines of the display may indicate an alarm for a point unrelated to the
requested point information displayed below them.
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A TUE JAN 25, 2011
READ ADDRESS: N124L03D052
AUTOMATIC INACTIVE
ELEVATOR LOBBY EAST WING
FIFTH FLOOR Z005 SMOKE(PHOTO)
Z005, Z027, Z066, , ,
,,,,,
VALUES: 011% OF ALARM, 045% OF PREALARM
ALARM: 6= 1.66%, PREALARM: 3= 0.47%
ACTION/STATUS: NONE/VERY CLEAN
PEAKS:56% VERIFY COUNT:02 CO-OP:D100,158
10:22:34A TUE JAN 25, 2011
BACK
PEAKS:56% COUNT:02 CO:200PPM TEMP: 100
o
F
For FSC-851 detectors, the values appear in line
14 above. Refer to More Information on page 19
for explanation of fields.
