78 NFS2-3030 Operations Manual — P/N 52546:N1 06/20//2014
Appendix A: Software Type ID Codes
A.1 Alphabetical List
The following chart lists NFS2-3030 Type ID codes in alphabetical order. These codes are assigned
during programming based on the types and functions of the devices they are assigned. The codes
appear in point message formats.
Software Type ID Code Device
ABORT SWITCH Monitor that provides an abort function for a releasing zone through connection to a UL-listed
abort station)
ACCESS MONTR Monitor for building access
ACK SWITCH Monitor used to silence panel sounder, and to give an acknowledge message on the panel
display
AIR REF FSL-751 detector used to monitor air quality entering a protected area
ALARMS PEND Control module or NAC for output that will activate upon receipt of an alarm condition, and
remain in the alarm state until all alarms have been acknowledged. Programmed for switch
inhibit
ALARM TRACK Monitor used to monitor fire alarm equipment
ALLCALL PAGE Monitor used for emulation of AMG-1 All-call switch, activating all speaker circuits
AREA MONITOR Monitor for building access
ASPIR. (NON) For use with an aspiration detector, reports to the fire panel as a non-fire event when its
threshold is reached
ASPIR. (PRE) For use with an aspiration detector, reports to the fire panel as a prealarm condition when its
threshold is reached
ASPIR. (REF) For use with an aspiration detector, reports to the fire panel as a non-fire activation, used as a
reference for other aspiration detectors on the loop
ASPIR. (SUP) For use with an aspiration detector, reports to the fire panel as a supervisory when its threshold
is reached
ASPIRATION For use with an aspiration detector, reports to the fire panel as a fire alarm when threshold is
reached
AUDIBLE CKT Control module/ relay used on audible circuit NAC
AUDIO SYSTEM Monitor for audio equipment
BELL CIRCUIT Control module used with NAC with bells
blank Operates as CONTROL with no Type ID label
CO MONITOR Monitor Module for use with conventional CO detectors. Activation will generate a CO Alarm on
the FACP.
CONTROL Control module used with NAC
CONTROL NAC Control module or NAC
DRILL SWITCH Monitor used for activation that emulates panel Drill switch, activating silenceable fire outputs
ECS/MN MON Monitor for mass notification alarms, latching
ECS/MN SUPL Monitor for mass notification supervisory inputs, latching
ECS/MN SUPT Monitor for mass notification supervisory inputs, tracking
ECS/MN TMON Monitor used for mass notification trouble inputs, tracking
EQUIP MONITR Monitor used for recording access to equipment
EVACUATE SWITCH Monitor used for activation that emulates panel Drill switch, activating silenceable fire outputs
FIRE CONTROL Monitors non-fire activations
FMM-420 Monitors 4-20 mA industrial sensors
FORM C RESET Control module used to interrupt 24V power to four-wire conventional detectors for 30 seconds
upon reset. Used in conjunction with a monitor module with a conventional detector Type ID
Table A.1 Software Type ID Codes, Alphabetical List (1 of 4)
