82 NFS2-3030 Operations Manual — P/N 52546:N1 06/20//2014
Appendix B: Releasing Zones
B.1 Introduction
The control panel provides ten Releasing Zones (ZR00-ZR09). These are special zones that can be
used for up to ten independent releasing operations. This section contains descriptions of each
releasing function option and an example of how Releasing Zone options work.
For instructions on programming Releasing Functions, refer to this panel’s programming manual.
Each Releasing Zone includes the following releasing options:
The Read Status function allows the operator to view the current selections for a Releasing Zone.
Refer to Section 3.10, “Releasing Zone”, on page 60 for more information.
Option Description
Cross Zone Cross Zones let you program the control panel to activate a Releasing Zone when two
or more detectors or modules are alarmed. Cross Zone selections are:
Yes Two or more detectors or modules are alarmed that are mapped to one of the
ten Releasing Zones (ZR00-ZR09).
Zone Two or more detectors or modules are alarmed that are mapped to two
different Software Zones and mapped to one of the ten Releasing Zones
(R0-R9).
Heat At least one smoke detector mapped to one of the ten Releasing Zones
(ZR00-ZR09) is alarmed and at least one heat detector mapped to the same
Releasing Zone as the smoke detector is alarmed.
None Cross Zones are not used.
Delay Timer A 0–60 second programmable delay before activating a zone.
Abort Switch An Abort Switch Type Code used to abort activation of a zone.
Manual Release Allows immediate zone activation by overriding the abort function, cross-zone
function, and delay timer.
Soak Timer Automatically shuts off the releasing device after a preprogrammed period of time.
Select 0001-9999 seconds for Soak Time or 0000 seconds for no Soak Time.
Table B.1 Releasing Options
