Printing Reports Installed Points Report Screen
5.5 Installed Points Report Screen
This screen displays when the INSTALLED POINTS soft key is pressed on the PRINTER
FUNCTIONS screen (refer to Figure 5.1 on page 69)
Figure 5.5 Print Programming Screen
Soft Keys
SLC POINTS:Press to print information on installed SLC points. When the soft key is pressed, a
field appears to allow choice of a single SLC or ALL. Toggle until the desired choice appears in the
field, then press ACCEPT. The report looks like this.
INSTALLED POINTS MENU
SLC POINTS RELEASING ZONES
SPECIAL ZONES
GENERAL ZONES TROUBLE ZONES
LOGIC ZONES RANGE
ACS BACK
NORMAL SMOKE (ION) Detector L02D129 *** *** NTL*Y *** ** 6666
Z002 , , , , , , ,
, , L02D129
Status
Software
Type ID
Detector
or Module
Point label,
extended label
Multi-Detector
Co-op
Addresses
Local Mode Participation (Y or N)
Alarm Tracking (T) or Latching (L)
Pre-alarm Alert (T) or Action (L)
Alarm Verification Testing (V or *)
Custom
Action
Message
No.
Weekly
Occupancy
Schedule No.
Left to right - Alarm Threshold occupied, Alarm Threshold unoccupied,
Prealarm Threshold occupied, Prealarm Threshold unoccupied
******INSTALLED POINTS**********************************************************
NORMAL SMOKE (ION) Detector L02D129 *** *** NTL*Y *** ** 6666
Z002,,,,,,,
, , L02D129
ON RELAY Module L02M005 NL * *** **
ZL001,,,,,,,
, , L02M005
********************************************************************************
Device
Address
Ten zone fields of zone map (separated by commas)
Field Identification
SLC Detector Installed Points
Silenceable (S or * - Sounder/Relay Base Only)
To Next Page
