Troubleshooting
- 337 -
When paper is jammed
For the error code 370 or 371
1
Remove the jammed paper from the output exit.
2
Pull the front cover open lever (blue) to open the front cover.
3
Pull the L2 lever and lift the output tray until it reaches the stop position.
4
Remove the paper left on the belt unit if any.
Doing so may cause burns.
Do not touch the fuser unit because it is hot.
Because image drums (green parts) can easily get damaged, handle with adequate care.
Do not expose the image drum to direct sunlight or strong light (About 1,500 lux or above). Do not leave it
uncovered for more than 5 minutes even under room lighting.
To Next Page
