1 Features and System Configuration
CJ-series PROFIBUS Master Unit Operation Manual for NJ-series CPU Unit (W509)
1-3 CX-ConfiguratorFDT
1
1-3-1 CX-ConfiguratorFDT Features
1-3 CX-ConfiguratorFDT
 CX-ConfiguratorFDT
The PROFIBUS Master Unit requires a configuration before it can exchange I/O data with the slave
devices. For this purpose OMRON provides the CX-ConfiguratorFDT Configuration program, which
runs under Microsoft Windows™ NT 4.0, Windows™ 2000, Windows™ XP or Windows™ 7.
Together with CX-ConfiguratorFDT, OMRON provides the following DTM COM Objects:
• A DTM to configure the CJ1W-PRM21 PROFIBUS DP-V1 Master
• A DTM to configure the CJ1W-PRM21 PROFIBUS DP Master
• A DTM to configure the SmartSlice GRT1-series GRT1-PRT.
• A DTM to allow the handling of classic GSD files in CX-ConfiguratorFDT
The following provides a quick overview of the functions.
 CX-ConfiguratorFDT Container Application
CX-ConfiguratorFDT provides an FDT environment in which DTMs can be executed. The main func-
tion of CX-ConfiguratorFDT is to facilitate the DTMs and the data exchange between them. It pro-
vides:
• Network setup functions: A tree view shows the relations between the DTMs, i.e. the relation
between the Master and slave devices.
• Device Catalogue functions: A Device Catalogue containing the installed DTMs is maintained,
to which the user can add new DTMs or delete them. Device DTMs can be added to the net-
work from this Catalogue.
• Project maintenance functions: CX-ConfiguratorFDT provides the functions to create, save
and open project files. It facilitates user access control, which limits of use to authorized per-
sonnel only, using password protection.
• Additional functions: CX-ConfiguratorFDT provides additional functions like printing, error log-
ging, FDT Communication logging and help files.
 CJ1W-PRM21 PROFIBUS DP-V1 DTM
The CJ1W-PRM21 DTM provided to configure the CJ1W-PRM21 PROFIBUS DP-V1 Master Unit
provides:
• The Settings User Interface, which handles the configuration for the PROFIBUS Master Unit.
This includes the bus parameters settings, the I/O data mappings and Master specific set-
tings. The Settings DTM provides its own user interface.
• The Monitoring User Interface, which handles the status monitoring and control over the
PROFIBUS Master Unit, when it is on-line and communicating over the PROFIBUS network.
It provides its own user interface to read out Master status flags and Error log, as well as
Slave status flags and the Slave diagnostics messages received by the Unit. It also allows the
user to send Global-Control commands over the network and to change the PROFIBUS Mas-
ter Unit’s mode on the PROFIBUS network.
• The communication interface between the CJ1W-PRM21 DTMs and CX-Server. CX-Server,
provided with the CX-ConfiguratorFDT package, is the driver for communication between the
PC and the NJ-series Controller Unit.
• A communication channel to the user to change a remote slave device address. This channel
has its own user interface.
