Omron CP1E - INTRODUCTION User Manual

A
Appendix
102 SYSMAC CP1L/CP1E Introduction Manual
Appendix
A-1 Channel/Relay Numbers
In CP1L or CP1E, channel (CH) numbers and relay numbers are specified as described below.
Each channel consists of 16 bits.
Hence, relay numbers are expressed as [channel number] + [bit number (00 to
15)].
Relay numbers are used to handle contacts. Channel numbers are mainly used
as operands for special instructions when processing data by the channel.
Note In CX-Programmer (abbreviated as CX-P below), upper bits of channel
numbers and relay numbers are not displayed if their value is 0. For example,
0000CH will be displayed as 0.
Relay numbers are displayed as a channel number followed by a period and a
bit number. The bit number ranges in value from 00 to 15.
■CP1L CPU Units
*1 H512 to H1535 is FB special area.
*2 For 10/14/20-point I/O units: D0 to D9999, D32000 to D32767.
Note The work words in CIO Area may be assigned to new functions in future
versions of the CPU Units. Be sure to use the work words in W000 to W511CH
first.
■CP1E CPU Units
Area Channel Relay
In CX-P In CX-P
CIO
area
I/O area 00 to 199 0 to 199 00000 to 19915 0.00 to 199.15
1:1 link area 3000 to 3063 CH 3000 to 3063 300000 to 306300 3000.00 to 3063.00
Serial PLC link area 3100 to 3189 CH 3100 to 3189 310000 to 318915 3100.00 to 3189.15
Work area 3800 to 6143 CH 3800 to 6143 380000 to 614300 3800.00 to 6143.00
Work area W000 to W511 CH W000 to W511 W00000 to W51115 W0.00 to W511.15
Holding area
H000 to H1535 CH*
1
H000 to H1535*
1
H00000 to H153515*
1
H0.00 to H1535.15*
1
Auxiliary area A000 to A959 CH A000 to A959 A00000 to A95915 A0.00 to A959.15
DM area
D00000 to D32767*
2
D0 to D32767*
2
--
Timer T000 to T4095 T0 to T4095 T000 to T4095 T0000 to T4095
Counter C000 to C4095 C000 to C4095 C000 to C4095 C0000 to C4095
Area Channel Relay
In CX-P In CX-P
CIO
area
I/O area 000 to 199 0 to 199 00000 to 19915 0.00 to 199.15
Serial PLC link area 200 to 289 CH 200 to 289 20000 to 28915 200.00 to 289.15
Work area W00 to W099 CH W00 to W99 W0000 to W9915 W0.00 to W99.15
Holding area H00 to H49 CH H0 to H49 H0000 to H4915 H0.00 to H49.15
Auxiliary area A000 to A753 CH A000 to A753 A00000 to A75315 A0.00 to A753.15
DM
area
E-type D00000 to D02047 D0 to D02047 - -
N-type D00000 to D08191 D0 to D08191 - -
Timer T000 to T255 T0 to T255 T000 to T255 T0000 to T0255
Counter C000 to C255 C000 to C255 C000 to C255 C0000 to C0255
