Omron CP1E - INTRODUCTION User Manual

4-7 Editing Programs
4
4
78 SYSMAC CP1L/CP1E Introduction Manual
Creating Programs
2. Double-click the address for which you wish to input or edit the I/O
comment.
The I/O comment field will become editable. Input or edit the I/O comment.
Note In Smart Input Mode, an I/O comment can be input after an operand has been
input using the comment dialog box.
The Comment dialog box shown above is displayed only when [Show with
comment dialog] is selected on the Options - Diagrams dialog box. The Options -
Diagrams dialog box is accessed by selecting [Options] from the Tools menu.
4-7-2 Inputting Rung Comments
Comments can be added to each rung of a ladder program.
1. Double-click the rung header for the rung you wish to add a comment to.
The Rung Properties dialog box will be displayed.
