Omron CP1E - INTRODUCTION User Manual

4-2 Creating Ladder Programs
4
4
SYSMAC CP1L/CP1E Introduction Manual 47
Creating Programs
4-2-2 Ladder Program
The ladder program for the example application is shown below.
Creating the program in CX-Programmer will be explained in the next section.
W0.00
TIM
0000
#50
Work area * 4
T0000
Timer * 3
0.04
Light detection
sensor * 1
W0.00
Work area * 2
W0.00
Work area
0.04
Light detection sensor
T0000
Timer
C0000
Counter
A200.11
P_First_Cycle First cycle flag * 7
C0000
Counter
0.01
STOP button
0.05
Upper
limit LS
100.01
De-escalation
motor
100.00
Escalation
motor
0.00
OPEN button
100.00
Escalation
motor
0.01
CLOSE button
0.06
Lower
limit LS
100.00
Escalation
motor
100.01
De-escalation
motor
0.03
Car detection sensor * 8
0.02
CLOSE button
100.01
De-escalation
motor
Timer * 5
Counter * 6
#3
CNT
0000
* 1 Refer to Inputting Contacts of 4-5-2 Inputting Contacts.
* 2 Refer to Inputting OR Circuits of 4-5-2 Inputting Contacts.
* 3 Refer to Inputting Closed Contacts of 4-5-2 Inputting Contacts.
* 4 Refer to 4-5-3 Inputting Output Coils.
* 5 Refer to 4-5-4 Inputting Timers.
* 6 Refer to 4-5-5 Inputting Counters.
* 7 Refer to 4-5-6 Inputting Auxiliary Areas.
* 8 Refer to 4-5-7 Inputting Differentiated Up Contacts.
