A-5 Comparison between CP1L and CP1E
178 SYSMAC CP1L/CP1E Introduction Manual
Appendix
A-5-2 CP1L Instructions not Supported by the CP1E
Classification Mnemonic
Sequence Input and
Output Instructions
•LD TST
• LD TSTN
•AND TST
•AND TSTN
•OR TST
•OR TSTN
•OUTB
Sequence Control
Instructions
•CJPN
•JMP0
•JME0
Timer and Counter
Instructions
• MTIM/MTIMX
Comparison
Instructions
•MCMP
•BCMP2
Data Movement
Instructions
•MVNL
•XCGL
•MOVR
•MOVRW
Data Shift Instructions
•ASFT
•ASLL
•ASRL
•ROLL
•RLNC
•RLNL
•RORL
• RRNC
• RRNL
•NSFL
•NSFR
Symbol Math
Instructions
•*U
•*UL
•/U
•/UL
Conversion Instructions
•NEGL
•SIGN
•LINE
•COLM
•BINS
•BISL
•BCDS
•BDSL
•GRY
Logic Instructions
•XNRW
•XNRL
Special Math
Instructions
•ROTB
•ROOT
•FDIV
Floating-point Math
Instructions
•RAD
•DEG
•SIN
•COS
•TAN
•ASIN
•ACOS
•ATAN
•SQRT
•EXP
•LOG
•
PWR
Double-precision
Floating-point
Instructions
•FIXD
•FIXLD
•DBL
•DBLL
Classification Mnemonic
Double-precision
Floating-point
Instructions
•+D
•-D
•*D
•/D
•RADD
•DEGD
•SIND
•COSD
•TAND
•ASIND
•ACOSD
•ATAND
•SQRTD
•EXPD
• LOGD
•PWRD
• LD, AND, OR +
=D, <>D, <D,
<=D, >D, or >=D
Table Data Processing
Instructions
•SSET
•PUSH
•FIFO
•LIFO
•DIM
•SETR
•GETR
• SRCH
•MAX
•MIN
•SUM
•SNUM
• SREAD
•SWRIT
•SINS
•SDEL
Data Control
Instructions
•PID
•LMT
•BAND
•ZONE
Subroutine Instructions
• MCRO
•GSBS
•GSBN
•GRET
Interrupt Control
Instructions
•MSKR
High-speed Counter
and Pulse Output
lnstructions
•PRV2
Basic I/O Unit
Instructions
•IORD
•IOWR
•TKY
•HKY
•DLNK
Serial Communications
Instructions
•PMCR
•TXDU
•RXDU
STUP
Network Instructions
•SEND
•RECV
•CMND
•EXPLT
•EGATR
•ESATR
• ECHRD
•ECHWR
Classification Mnemonic
Display Instructions
•MSG
•SCH
•SCTRL
Clock Instructions
•SEC
•HMS
Debugging Instructions
•TRSM
Failure Diagnosis
Instructions
•FPD
Other Instructions
• CCS
• CCL
•FRMCV
•TOCV
Block Programming
Instructions
•BPRG
•BEND
•BPPS
•BPRS
•EXIT
•EXIT NOT
•IF
•IF NOT
•ELSE
•IEND
•WAIT
•WAIT NOT
•TIMW
•TIMWX
• CNTW
• CNTWX
•TMHW
•TMHWX
• LOOP
•LEND
• LEND NOT
Text String Processing
Instructions
•MOV$
•+$
•LEFT$
•RGHT$
•MID$
•FIND$
•LEN$
•RPLC$
•DEL$
•XCHG$
•CLR$
•INS$
• =$, <>$, <$,
<=$,>$, >=$
Task Control
Instructions
•TKON
•TKOF
Model Conversion
Instructions
•XFERC
•DISTC
• COLLC
