67
High-speed Counter Board Section 2-1
IR 212 AR 05 00 High-speed counter 1 Reset Bit Phase Z and software reset
0: Counter not reset on phase Z
1: Counter reset on phase Z
Software reset only
0: Counter not reset
0→1: Counter reset
01 High-speed counter 2 Reset Bit
02 High-speed counter 3 Reset Bit
03 High-speed counter 4 Reset Bit
08 High-speed Counter 1 Comparison
Start Bit
0 → 1: Comparison starts
1 → 0: Comparison stops
09 High-speed Counter 2 Comparison
Start Bit
10 High-speed Counter 3 Comparison
Start Bit
11 High-speed Counter 4 Comparison
Start Bit
12 High-speed Counter 1 Stop Bit 0: Operation continues
1: Operation stops
13 High-speed Counter 2 Stop Bit
14 High-speed Counter 3 Stop Bit
15 High-speed Counter 4 Stop Bit
IR 213 AR 06 00 External Output 1 Force-set Bit 0: No effect on output status
1: Forces output ON
01 External Output 2 Force-set Bit
02 External Output 3 Force-set Bit
03 External Output 4 Force-set Bit
04 External Output Force-set Enable Bit 0: Force-setting of outputs 1 to 4 disabled
1: Force-setting of outputs 1 to 4 enabled
SR 254 15 Inner Board Error Flag 0: No error
1: Error
Turns ON when an error occurs in an Inner
Board mounted in slot 1 or slot 2. The error
code for slot 1 is stored in AR 0400 to AR
0407 and the error code for slot 2 is stored
in AR 0408 to AR 0415.
AR 04 00 to 07 Error code for Inner Board in slot 1 00 Hex: Normal
01 or 02 Hex: Hardware error
03 Hex: PC Setup error
08 to 15 Error code for Inner Board in slot 2
Word Bits Name Function
Slot 1 Slot 2
