Communications Function Section 1-4
Note The Protocol Setting parameter is displayed only when CompoWay/F commu-
nications are being used.
Setting Communications
Data
Match the communications specifications of the E5CN/AN/EN/GN and the
host computer. If a 1:N connection is being used, ensure that the communica-
tions specifications for all devices in the system (except the communications
Unit No.) are the same.
M
M
M
M
M
M
M
psel
cwf
u-no
1
bps
9.6
len
7
sbit
2
prty
even
sdwt
20
Protocol Setting
Communications Unit No.
Communications Baud Rate
Communications Parity
Send Data Wait Time
Communications Data Length
(See note.)
Communications Stop Bits
(See note.)
Parameter name Symbol Setting (monitor) value Selection symbols Default Unit
Protocol Setting psel CompoWay/F (SYSWAY),
Modbus
cwf, mod CompoWay/F
(SYSWAY)
None
Communications
Unit No.
u-no 0 to 99 1 None
Communications
Baud Rate
bps 1.2, 2.4, 4.8, 9.6, 19.2,
38.4, 57.6
1.2, 2.4, 4.8, 9.6, 19.2, 38.4.
57.6
9.6 kbps
Communications
Data Length
len 7, 8 7 Bits
Communications
Stop Bits
sbit 1, 2 2 Bits
Communications
Parity
prty None, Even, Odd none, even, odd Even None
Send Data Wait
Time
sdwe 0 to 99 20 ms
