68 LD-250 Platform User's Guide 20472-000 Rev B
4.1 î ±Settings and Configuration
Network Feature Default Network Setting
Identifier (SSID) Wireless Network
Security method Unsecured
LD-250 Default Network Settings.
Features of the Maintenance Ethernet Port
The following important considerations apply to the LD-250's Maintenance Ethernet port:
l
You cannot change its default address (1.2.3.4) or use that same address elsewhere on
the same network. Doing so could cause a network conflict, preventing proper and safe
operation of the AMR.
l
Do not connect the AMR's maintenance Ethernet port to your LAN. Omron intends that
you use this port only for single connection for debugging or initial setup purposes. The
User LAN port provides an Ethernet connection for your LAN.
l Access to the SetNetGo Web UI is always enabled on this port. It does not require either
a password or a software license.
Consult your network systems administrator before using SetNetGo to change any default set-
tings. See the Fleet Operations Workspace Core User's Guide for information abut modifying net-
work settings.
Configure the LD-250's Network
To configure the LD-250's network, you require:
l One Ethernet patch cable, minimum Cat-5 specification. This cable should be of suf-
ficient length that you can connect your PC to the AMR and work comfortably.
l An IP address in the range 1.2.3.0 to 1.2.3.255, excluding 1.2.3.4, which is the permanent
address assigned to the LD-250 Maintenance port
Use the following procedure to set up the network on the LD-250.
1.
Connect an Ethernet cable from the Maintenance Ethernet port on the LD-250 to an Eth-
ernet port on your Microsoft Windows PC.
Figure 4-1 Connecting an Ethernet Cable
