Omron USB3 Vision Series User Manual

No.17S010-01
13/68
STC-MBS43U3V / STC-MCS43U3V / STC-MBS163U3V / STC-MCS163U3V
Product Specifications and Use’s Guide
Model Number STC-MBS163U3V STC-MCS163U3V
Image Sensor 1/2.9” 1.6M Progressive Monochrome CMOS
(SONY: IMX273)
1/2.9” 1.6M Progressive Color CMOS
(SONY: IMX273)
Shutter Type Global
Active Picture Elements 1,440 (H) x 1,080 (V)
Cell Size 3.45 (H) x 3.45 (V) µm
Sync System
External trigger (Hardware, Software) / Free run
Maximum 8bits output (*1)
238.0 fps (Frame rate prioritized mode) / 200.5 fps (Image quality prioritized mode)
Frame Rate 10bits output 118.1 fps
(at Full 10bits Packed output 183.8 fps
scanning) 12bits output 117.3 fps
12bits Packed output 157.5 fps
ADC bit width 10bits / 12bits
Video Format
8bits / 10bits / 12bits output
(Support packed on 10bits / 12bits)
Noise Level 8bits output Less than 6 digits (Gain 0 dB, Frame rate prioritized) /
Less than 3 digits (Gain 0 dB, Image quality prioritized)
10bits / 10bits Packed output Less than 12 digits (Gain 0 dB)
12bits / 12bits Packed output Less than 48 digits (Gain 0 dB)
Sensitivity (*2) 8bits (Frame rate prioritized): 108 Lux
8bits (Image quality prioritized) / 10bits /12bits:
430 Lux
8bits (Frame rate prioritized): 240 Lux
8bits (Image quality prioritized) / 10bits /12bits:
960 Lux
Exposure time 8bits output
1 µsecond to 16.777 seconds (Default: 4.05736 mseconds)
10bits output
10bits Packed output
12bits output
12bits Packed output
Gain Analog Gain
0 to 19.2 dB (Default: 0 dB)
Digital Gain
x1 to x2 (Default: x1)
Black Level 8bits output 0 to 31 digits
10bits / 10bits Packed output 0 to 127 digits
12bits / 12bits Packed output 0 to 511 digits
White Balance Gain N/A
0 (Black level) to x3.99 (Default: x1)
ROI (*3) Horizontal: 64 to 1,440 (1,408 on Packed) pixels / Vertical: 4 to 1,080 lines
(Default: 1,440 x 1,080)
Adjustable Steps for image size:
16 pixels in horizontal direction (64 pixels on Packed) / 4 lines in vertical direction
Adjustable Steps for offset: 4 pixels in horizontal direction / 4 lines in vertical direction
Multi ROIs N/A
Gamma
Gamma Table = 0.1 to 4.0 (Default = 1.0)
Binning
Individual x2 Horizontal, Vertical Binning / Off
(Horizontal: Average, Vertical: Addition) (*8)
N/A
Decimation
Individual x2 Horizontal, Vertical Decimation / Off
Image Flip
Horizontal / Vertical / Horizontal and Vertical / Off
Defective Pixel Correction Up to 2,048 points
Default: Bold
