Omron USB3 Vision Series User Manual

No.17S010-01
38/68
STC-MBS43U3V / STC-MCS43U3V / STC-MBS163U3V / STC-MCS163U3V
Product Specifications and Use’s Guide
High or low level signal that was configured on the software is output.
Setting Procedure
Selects Line N (N: any number from 0, 1 or 2)
1) Sets the User Output N (N is Line number) as Line Source
2) Selects User Output N (N is same as selected Line number on User Output) on User Output Selector
3) Sets the value (True: High level, False: Low level) on User Output Value
Monitor the status on output port.
Monitor the output voltage level High (Line Status: true) or Low (Line Status: false) through the software.
Some selectable functions can be modified in order to add to the duration or pulse width on Line Source.
The configurable parameters are shown in the chart below.
Please refer to Line Source for the applicable functions of Parameters.
GenICamParameters
TriggerOutDelay Integer Type Trigger Out Delay Time
Range: 0 to 262,143 μseconds, Default: 0 μsecond
TriggerOutOnTime Integer Type Trigger Out On Time
Range: 4 to 262,143 μseconds, Default: 32 μseconds
StrobeOutDelay Integer Type Strobe Out Delay Time
Range: 0 to 262,143 μseconds, Default: 30 μseconds
StrobeOutOnTime Integer Type Strobe Out On Time
Range: 4 to 262,143 μseconds, Default: 32 μseconds
8.3 Hardware Reset
The hardware reset can be done by CAM_RESET port.
Sets On (Default: Off) at Line Device Reset Mode, and apply the Low voltage in 5 seconds on CAM_RESET port then
camera rest.
