Panasonic SDR-H80 User Manual

12
LSQT1484
Push the battery against the battery
holder and slide it until it clicks.
≥ Be sure to set the mode dial to OFF and check that the status indicator is off before removing the
battery.
≥ Do not heat or expose to flame.
≥ Do not leave the battery(ies) in an automobile exposed to direct sunlight for a long period of time with
doors and windows closed.
Inserting the battery
Removing the battery
While sliding the BATTERY lever, slide the
battery to remove it.
≥ Hold the battery with your hand so that it
does not fall.
CAUTION
Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type recommended by the
manufacturer. Dispose of used batteries
according to the manufacturer’s instructions.
Warning
Risk of fire, explosion and burns. Do not
disassemble, heat above 60 xC or incinerate.
SDR-H90&80GN-LSQT1484_mst.book 12 ページ ２００８年１２月１９日 金曜日 午後４時８分

Panasonic SDR-H80 Specifications

General

Filter size	37 mm
Digital zoom	100 x
Optical zoom	70 x
Image stabilizer	Yes
Focal length range	1.5 - 105 mm
Focal length (35mm film equivalent)	38.5 - 2695 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Interface	USB 2.0, A/V out
Aperture range (F-F)	1.9 - 5.7
Audio recording formats	MPEG1
Power consumption (typical)	3.8 W
Display diagonal	2.7 \
Display resolution	704 x 576 pixels
Video formats supported	MPEG2
Camera shutter speed	1/25 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	1
Product color	Silver
Video recording time	54 h
Compatible memory cards	SD, SDHC
Internal storage capacity	60 GB

Weight and Dimensions

Depth	107 mm
Width	53 mm
Height	67 mm
Weight	300 g
