Panasonic SDR-H80 User Manual

83
LSQT1484
With a PC
Setup
1
Installation
When installing the software, log on to your PC
as the Administrator (or with a user name with
equivalent authorization) or with the user name
for a standard user account. (If you do not have
authorization to do this, consult your manager.)
≥ Before starting the installation, close any other
software applications which are running.
≥ Do not perform any other operations on your
PC while the software is being installed.
For Windows Vista:
If [User Account Control] dialogue appears, click
[Continue].
1 Insert the CD-ROM into the PC.
≥ If the installation screen does not appear
automatically, double-click the CD-ROM drive
icon in [My Computer (Computer)].
2 Click [Next].
3 Select where the application is to
be installed, then click [Next].
4 Select [Yes] or [No] to create
shortcut.
5 Select the country or region
where you live, then click [Next].
≥ If the country or region cannot be selected,
select [PAL Area].
≥ When the confirmation message appears, click
[Yes].
6 Click [Install] to start the
installation process.
7 When installation is complete, some notes
will appear
Check the contents, then close
the window.
Installing VideoCam Suite
SDR-H90&80GN-LSQT1484_mst.book 83 ページ ２００８年１２月１９日 金曜日 午後４時８分

Panasonic SDR-H80 Specifications

General

Filter size	37 mm
Digital zoom	100 x
Optical zoom	70 x
Image stabilizer	Yes
Focal length range	1.5 - 105 mm
Focal length (35mm film equivalent)	38.5 - 2695 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Interface	USB 2.0, A/V out
Aperture range (F-F)	1.9 - 5.7
Audio recording formats	MPEG1
Power consumption (typical)	3.8 W
Display diagonal	2.7 \
Display resolution	704 x 576 pixels
Video formats supported	MPEG2
Camera shutter speed	1/25 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	1
Product color	Silver
Video recording time	54 h
Compatible memory cards	SD, SDHC
Internal storage capacity	60 GB

Weight and Dimensions

Depth	107 mm
Width	53 mm
Height	67 mm
Weight	300 g
