Panasonic SDR-H80 User Manual

62
LSQT1484
Playback
Editing
4
Editing still pictures
¬Rotate the mode dial to select .
Function Operating method
Locking still pictures
[HDD] [SD]
This is for preventing still
picture files from being
deleted by mistake.
(However, please be aware
that if a medium is
formatted, then all the data
on the medium will be
erased.)
¬Select [HDD] or [SD CARD] in [MEDIA SELECT].
1 Select the menu. (l 21)
[PHOTO SETUP] # [LOCK SET] # [YES]
2 Select the file to be protected, then press the
joystick.
[ ] appears and the selected file is locked.
≥ Press the joystick again to release the lock setting.
≥ You can also select multiple files in succession.
To complete the settings
Press the MENU button.
SDR-H90&80GN-LSQT1484_mst.book 62 ページ ２００８年１２月１９日 金曜日 午後４時８分

Panasonic SDR-H80 Specifications

General

Filter size	37 mm
Digital zoom	100 x
Optical zoom	70 x
Image stabilizer	Yes
Focal length range	1.5 - 105 mm
Focal length (35mm film equivalent)	38.5 - 2695 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Interface	USB 2.0, A/V out
Aperture range (F-F)	1.9 - 5.7
Audio recording formats	MPEG1
Power consumption (typical)	3.8 W
Display diagonal	2.7 \
Display resolution	704 x 576 pixels
Video formats supported	MPEG2
Camera shutter speed	1/25 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	1
Product color	Silver
Video recording time	54 h
Compatible memory cards	SD, SDHC
Internal storage capacity	60 GB

Weight and Dimensions

Depth	107 mm
Width	53 mm
Height	67 mm
Weight	300 g
