Panasonic SDR-H80 User Manual

51
LSQT1484
Scenes recorded on the same day can be played
back in succession.
1 Select (BY DATE), then press
the joystick.
2 Select the playback date, then
press the joystick.
(When playing back motion pictures on the HDD)
(When playing back motion pictures on the SD
card)
3 Select the scene to be played
back, then press the joystick.
To select a different date
Select (BY DATE), then press the joystick.
To return to the screen showing all scenes
Select (VIEW ALL), then press the joystick.
≥ Even if scenes are recorded on the same day,
they are grouped separately in the following
cases.
jWhen the number of scenes exceeds 99
jWhen the world time setting is changed
Creating a new playlist (l 59)
[HDD]
1 Select (PLAYLIST), then press
the joystick.
2 Select the playlist to be played
back, then press the joystick.
3 Select the scene to start
playback, then press the joystick.
To select a different playlist
Select (PLAYLIST), then press the joystick.
To return to the screen showing the original
scenes
Select (VIEW ALL), then press the joystick.
Playing back motion pictures by
date
Playing back a playlist
SDR-H90&80GN-LSQT1484_mst.book 51 ページ ２００８年１２月１９日 金曜日 午後４時８分

Panasonic SDR-H80 Specifications

General

Filter size	37 mm
Digital zoom	100 x
Optical zoom	70 x
Image stabilizer	Yes
Focal length range	1.5 - 105 mm
Focal length (35mm film equivalent)	38.5 - 2695 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Interface	USB 2.0, A/V out
Aperture range (F-F)	1.9 - 5.7
Audio recording formats	MPEG1
Power consumption (typical)	3.8 W
Display diagonal	2.7 \
Display resolution	704 x 576 pixels
Video formats supported	MPEG2
Camera shutter speed	1/25 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	1
Product color	Silver
Video recording time	54 h
Compatible memory cards	SD, SDHC
Internal storage capacity	60 GB

Weight and Dimensions

Depth	107 mm
Width	53 mm
Height	67 mm
Weight	300 g
