Panasonic SDR-H80 User Manual

13
LSQT1484
∫ Charging time
≥ Temperature: 25 oC/humidity: 60%
≥ If the temperature is higher or lower than 25 oC, the charging time will become longer.
∫ Recordable time
≥ Temperature: 25 oC/humidity: 60%
* The battery pack holder kit VW-VH04 (optional) is necessary.
≥ These times are approximations.
≥ The actual recordable time refers to the recordable time when repeatedly starting/stopping recording,
turning the unit on/off, moving the zoom lever, etc.
≥ The recordable times will vary depending on the status of use. Be aware that the operating time of the
battery will become shorter in low temperatures. We recommend charging a spare battery for use
when recording.
≥ The batteries heat up after use or charging. This unit will also heat up while being used. This is not a
malfunction.
Charging time and recordable time
Battery model number Voltage/Capacity (Minimum) Charging time
Supplied battery/VW-VBG070
(optional)
7.2 V/725 mAh 1 h 35 min
VW-VBG130 (optional) 7.2 V/1250 mAh 2 h 35 min
VW-VBG260 (optional) 7.2 V/2500 mAh 4 h 40 min
VW-VBG6* (optional) 7.2 V/5400 mAh 9 h 25 min
Battery model
number
Voltage/
Capacity
(Minimum)
Recording
destination
Recording
mode
Maximum
continuously
recordable
time
Actual
recordable
time
Supplied battery/
VW-VBG070
(optional)
7.2 V/
725 mAh
[HDD]
XP 1h50min 55min
SP/LP 1h55min 1h
[SD] XP/SP/LP 2h 1h5min
VW-VBG130
(optional)
7.2 V/
1250 mAh
[HDD]
XP 2h55min 1h30min
SP/LP 3 h 1 h 35 min
[SD] XP/SP/LP 3 h 10 min 1 h 45 min
VW-VBG260
(optional)
7.2 V/
2500 mAh
[HDD]
XP 5h20min 2h50min
SP/LP 5h35min 2h55min
[SD] XP/SP/LP 5 h 50 min 3 h 15 min
VW-VBG6*
(optional)
7.2 V/
5400 mAh
[HDD]
XP 13h20min 7h
SP/LP 13h50min 7h20min
[SD] XP/SP/LP 14h30min 8h5min
SDR-H90&80GN-LSQT1484_mst.book 13 ページ ２００８年１２月１９日 金曜日 午後４時８分

Panasonic SDR-H80 Specifications

General

Filter size	37 mm
Digital zoom	100 x
Optical zoom	70 x
Image stabilizer	Yes
Focal length range	1.5 - 105 mm
Focal length (35mm film equivalent)	38.5 - 2695 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Interface	USB 2.0, A/V out
Aperture range (F-F)	1.9 - 5.7
Audio recording formats	MPEG1
Power consumption (typical)	3.8 W
Display diagonal	2.7 \
Display resolution	704 x 576 pixels
Video formats supported	MPEG2
Camera shutter speed	1/25 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	1
Product color	Silver
Video recording time	54 h
Compatible memory cards	SD, SDHC
Internal storage capacity	60 GB

Weight and Dimensions

Depth	107 mm
Width	53 mm
Height	67 mm
Weight	300 g
