Panasonic SDR-H80 User Manual

37
LSQT1484
Recording
Recording
(Advanced)
1
Recording functions of
operation icons
[HDD] [SD]
Set the recording functions by selecting the operation icons to add different effects to the recorded
images.
¬Rotate the mode dial to select or .
1 Press the joystick, and icons will be displayed on the screen.
≥ The indication changes each time the joystick is moved down.
≥ The indication disappears when the centre of the joystick is pressed again.
2 Select an icon with the joystick.
To cancel the function
Select the icon again.
ENTER
1/31/3 NEXTNEXT1/3 NEXT
1/3NEXT1/3NEXT1/3NEXT
SDR-H90&80GN-LSQT1484_mst.book 37 ページ ２００８年１２月１９日 金曜日 午後４時８分

Panasonic SDR-H80 Specifications

General

Filter size	37 mm
Digital zoom	100 x
Optical zoom	70 x
Image stabilizer	Yes
Focal length range	1.5 - 105 mm
Focal length (35mm film equivalent)	38.5 - 2695 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Interface	USB 2.0, A/V out
Aperture range (F-F)	1.9 - 5.7
Audio recording formats	MPEG1
Power consumption (typical)	3.8 W
Display diagonal	2.7 \
Display resolution	704 x 576 pixels
Video formats supported	MPEG2
Camera shutter speed	1/25 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	1
Product color	Silver
Video recording time	54 h
Compatible memory cards	SD, SDHC
Internal storage capacity	60 GB

Weight and Dimensions

Depth	107 mm
Width	53 mm
Height	67 mm
Weight	300 g
