Panasonic SDR-H80 User Manual

25
LSQT1484
It is possible to display and record the time at the travel destination by selecting your home region and
the travel destination.
1 Select the menu. (l 21)
≥ If the clock is not set, adjust the clock to the
current time. (l 24)
≥ When the [HOME] (your home region) is not
set, such as the time for the initial settings, the
message appears. Press the joystick to move
to Step 3.
2 (Only when setting your home region)
Select [HOME] and press the
joystick.
3 (Only when setting your home region)
Select your home region and
enter the selection with the
joystick.
≥ When the home is in summer time period,
move the joystick up. [ ] appears and
the summer time setting is turned on; the
clock is set forward by one hour. Move the
joystick up again to return to the normal
time setting.
≥ The current time appears on the left top of the
screen. The time difference from GMT
(Greenwich Mean Time) appears on the left
bottom of the screen.
4 (Only when setting the region of your travel
destination)
Select [DESTINATION] and press
the joystick.
≥ When the home region is set for the first time,
the screen for selecting home/travel
destination appears after setting the home
region successively. If the home region has
already been set once, execute the menu
operation for Step 1.
5 (Only when setting the region of your travel
destination)
Select your travel destination
and enter the selection with the
joystick.
≥ When the destination is in summer time
period, move the joystick up. [ ]
appears and the summer time setting is
turned on; the clock is set forward by one
hour. Move the joystick up again to return
to the normal time setting.
≥ The local time at the selected travel destination
appears on the right top of the screen. The
time difference between the travel destination
and the home region appears on the left
bottom of the screen.
≥ Close the setting by pressing the MENU
button. [ ] appears and the time of the
travel destination is indicated.
To return the display to the home setting
Set the home region using Step 1 to 3, and close
the setting by pressing the MENU button.
≥ If you cannot find your travel destination in the
area shown on the screen, set it by using the
time difference from your home region.
World time setting (Displaying the time of the travel
destination)
[BASIC] # [SET WORLD TIME] # [YES]
SDR-H90&80GN-LSQT1484_mst.book 25 ページ ２００８年１２月１９日 金曜日 午後４時８分

Panasonic SDR-H80 Specifications

General

Filter size	37 mm
Digital zoom	100 x
Optical zoom	70 x
Image stabilizer	Yes
Focal length range	1.5 - 105 mm
Focal length (35mm film equivalent)	38.5 - 2695 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Interface	USB 2.0, A/V out
Aperture range (F-F)	1.9 - 5.7
Audio recording formats	MPEG1
Power consumption (typical)	3.8 W
Display diagonal	2.7 \
Display resolution	704 x 576 pixels
Video formats supported	MPEG2
Camera shutter speed	1/25 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	1
Product color	Silver
Video recording time	54 h
Compatible memory cards	SD, SDHC
Internal storage capacity	60 GB

Weight and Dimensions

Depth	107 mm
Width	53 mm
Height	67 mm
Weight	300 g
