Panasonic SDR-H80 User Manual

75
LSQT1484
You can play back the motion pictures or the still pictures copied to a disc.
1 Connect this unit to the DVD burner. (l 70)
2 Select [PLAY DISC], then press the joystick.
≥ The motion pictures or the still pictures on the disc are displayed as thumbnails.
3 Select the scene/file to be played back, then press the joystick.
4 Select the playback operation with the joystick.
≥ The playback operation is the same as when playing back motion pictures or still pictures. (l 49, 52)
≥ After playback, eject the disc and disconnect the Mini AB USB Connection Cable.
Playing back a disc inserted in the DVD burner
ENTER
SDR-H90&80GN-LSQT1484_mst.book 75 ページ ２００８年１２月１９日 金曜日 午後４時８分

Panasonic SDR-H80 Specifications

General

Filter size	37 mm
Digital zoom	100 x
Optical zoom	70 x
Image stabilizer	Yes
Focal length range	1.5 - 105 mm
Focal length (35mm film equivalent)	38.5 - 2695 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Interface	USB 2.0, A/V out
Aperture range (F-F)	1.9 - 5.7
Audio recording formats	MPEG1
Power consumption (typical)	3.8 W
Display diagonal	2.7 \
Display resolution	704 x 576 pixels
Video formats supported	MPEG2
Camera shutter speed	1/25 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	1
Product color	Silver
Video recording time	54 h
Compatible memory cards	SD, SDHC
Internal storage capacity	60 GB

Weight and Dimensions

Depth	107 mm
Width	53 mm
Height	67 mm
Weight	300 g
