35
LSQT1484
The zoom microphone is linked to the zooming
operation so that far-away sounds with a tele-
shot and close-up sounds with a wide-angle shot
are recorded more clearly.
¬Rotate the mode dial to select .
Select the menu. (l 21)
¬Rotate the mode dial to select or
.
Rotate the LCD monitor towards the
lens side.
≥ The image is horizontally flipped as if you see
a mirror image. (However the image recorded
is the same as a normal recording.)
≥ When the LCD monitor is rotated towards the
lens side, the icon will not be displayed even if
you press the joystick.
≥ Only some indications will appear on the
screen. When [°] appears, return the
direction of the LCD monitor to normal position
and check the warning/alarm indication. (l 93)
This unit will resume recording/pause mode
about 0.8 seconds after the LCD monitor is
reopened.
≥ When in quick start standby mode about
60% of the power used in recording pause
mode is being consumed, so the recording
time will be reduced.
¬Rotate the mode dial to select or
.
1 Select the menu. (l 21)
2 Close the LCD monitor while the
mode dial is set to or .
The status indicator A flashes green and the unit
goes into quick start standby mode.
3 Open the LCD monitor.
The status indicator A lights red and the unit is
put into recording pause approx. 0.8 seconds
after it is turned on.
To cancel Quick start
Select [SETUP] # [QUICK START] # [OFF]
≥ The default setting is on.
≥ Quick start standby mode is cancelled if
jabout 5 minutes elapsed
jthe mode dial is switched
jthe battery is removed or the AC adaptor is
disconnected
To use the zoom microphone
function
[ADVANCED] # [ZOOM MIC] # [ON]
Recording yourself
Quick start
[SETUP] # [QUICK START] # [ON]
SDR-H90&80GN-LSQT1484_mst.book 35 ページ ２００８年１２月１９日 金曜日 午後４時８分
