Panasonic SDR-H80 User Manual

71
LSQT1484
[HDD] [SD]
Images recorded on this unit can be backed up to discs.
Copied information is recorded in the motion picture scenes that are copied to a disc using the
DVD COPY function. It is possible to write only scenes that are added after copying or delete the
copied scenes as a group.
¬Connect this unit to the DVD burner. (l 70)
Copy all motion pictures or still pictures on any of
the media to discs.
1 Select menus with the following
procedures.
Copy scenes on the media, which are added
after being copied to the disc using the
DVD COPY function (scenes that the copied
icons ( ) are not indicated), to discs.
1 Select menus with the following
procedures.
2 Select [YES], then press the joystick.
≥ When a recorded DVD-RAM, DVD-RW, or CD-RW disc is inserted in the DVD burner, a message
confirming whether the contents of the disc can be erased or not is displayed. After confirming that
the data can be erased, select [YES].
≥ When a message appears indicating copying is complete, then press the joystick. If all scenes are
copied, it is possible to create another set with the same contents. Follow the instructions on the
screen.
To finish, eject the disc and disconnect the Mini AB USB Connection Cable.
≥ Press the MENU button in the middle of the operation to return to the initial menu screen.
DVD COPY function
1 Copying all the scenes to discs
[BURN DISC] # [HDD] or [SD CARD] #
[VIDEO] or [PICTURE]# [DVD COPY]
*
# [ALL SCENES]
*
* Only when [VIDEO] is selected.
2 Copying added scenes to discs
[BURN DISC] # [HDD] or [SD CARD] #
[VIDEO] # [DVD COPY] #
[ADDED SCENES]
∫ Copied icon ( )
The copied information is recorded in motion picture scenes that are copied to a disc using the
DVD COPY function, and [ ] is indicated on the thumbnail.
≥ Motion picture scenes indicated with [ ] can be deleted as a group using the delete menu.
(l 55)
≥ The copied information will be deleted when using the SPLIT&DELETE function to split and delete
scenes that were copied using the DVD COPY function. Therefore these scenes will be copied
again when using the ADDED SCENES function.
A The number of discs necessary for copying by
disc type.
≥ When two or more discs are necessary for copying,
follow the on-screen instructions to switch discs.

SDR-H90&80GN-LSQT1484_mst.book 71 ページ ２００８年１２月１９日 金曜日 午後４時８分

Panasonic SDR-H80 Specifications

General

Filter size	37 mm
Digital zoom	100 x
Optical zoom	70 x
Image stabilizer	Yes
Focal length range	1.5 - 105 mm
Focal length (35mm film equivalent)	38.5 - 2695 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Interface	USB 2.0, A/V out
Aperture range (F-F)	1.9 - 5.7
Audio recording formats	MPEG1
Power consumption (typical)	3.8 W
Display diagonal	2.7 \
Display resolution	704 x 576 pixels
Video formats supported	MPEG2
Camera shutter speed	1/25 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	1
Product color	Silver
Video recording time	54 h
Compatible memory cards	SD, SDHC
Internal storage capacity	60 GB

Weight and Dimensions

Depth	107 mm
Width	53 mm
Height	67 mm
Weight	300 g
