21
LSQT1484
Preparation
Setup
2
Using the menu screen
1 Press the MENU button.
The menu displayed differs depending on the
position of the mode dial.
2 Select the desired top menu, then
move the joystick right or press
the joystick.
3 Select the submenu item, then
move the joystick right or press
the joystick.
4 Select the desired setting, then
press the joystick to enter the
selection.
To get back to the previous screen
Move the joystick left.
To exit the menu screen
Press the MENU button.
≥ Do not switch the mode dial when the menu is
displayed.
≥ The menu screen does not appear during
recording or playing. You cannot start other
operations while the menu screen is displayed.
MENU
ENTER
SDR-H90&80GN-LSQT1484_mst.book 21 ページ ２００８年１２月１９日 金曜日 午後４時８分

Panasonic SDR-H80 Specifications

General

Filter size	37 mm
Digital zoom	100 x
Optical zoom	70 x
Image stabilizer	Yes
Focal length range	1.5 - 105 mm
Focal length (35mm film equivalent)	38.5 - 2695 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Interface	USB 2.0, A/V out
Aperture range (F-F)	1.9 - 5.7
Audio recording formats	MPEG1
Power consumption (typical)	3.8 W
Display diagonal	2.7 \
Display resolution	704 x 576 pixels
Video formats supported	MPEG2
Camera shutter speed	1/25 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	1
Product color	Silver
Video recording time	54 h
Compatible memory cards	SD, SDHC
Internal storage capacity	60 GB

Weight and Dimensions

Depth	107 mm
Width	53 mm
Height	67 mm
Weight	300 g
