Panasonic SDR-H80 User Manual

89
LSQT1484
With a PC
Using a
Macintosh
1
If using a Macintosh
∫ Operating environment for the card reader function (mass storage)
≥ Even if the system requirements mentioned in these operating instructions are fulfilled, some
personal computers cannot be used.
≥ The USB equipment operates with the driver installed as standard in the OS.
≥ Supplied CD-ROM is available for Windows only.
∫ Copying still pictures on PC
1 Connect this unit to a PC via the
supplied USB cable.
≥ The USB function selection screen will appear.
2 Select [PC/RECORDER] # [HDD]
or [SD CARD] then press the
joystick.
3 Double-click [CAM_HDD] or
[CAM_SD] displayed on the
desktop.
≥ Files are stored in [100CDPFP] folder etc. in
the [DCIM] folder.
4 Drag and drop the files onto
destination folder (on the PC
hard disk).
∫ To disconnect USB cable safely
Drag [CAM_HDD] or [CAM_SD] disk
icon to the [Trash], and then
disconnect the USB cable.
Personal computer Macintosh
OS Mac OS X v10.4
Mac OS X v10.5
CPU PowerPC G5 (1.9 GHz or higher)
Intel Core Duo
Intel Core Solo
Interface USB port
SDR-H90&80GN-LSQT1484_mst.book 89 ページ ２００８年１２月１９日 金曜日 午後４時８分

Panasonic SDR-H80 Specifications

General

Filter size	37 mm
Digital zoom	100 x
Optical zoom	70 x
Image stabilizer	Yes
Focal length range	1.5 - 105 mm
Focal length (35mm film equivalent)	38.5 - 2695 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Interface	USB 2.0, A/V out
Aperture range (F-F)	1.9 - 5.7
Audio recording formats	MPEG1
Power consumption (typical)	3.8 W
Display diagonal	2.7 \
Display resolution	704 x 576 pixels
Video formats supported	MPEG2
Camera shutter speed	1/25 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	1
Product color	Silver
Video recording time	54 h
Compatible memory cards	SD, SDHC
Internal storage capacity	60 GB

Weight and Dimensions

Depth	107 mm
Width	53 mm
Height	67 mm
Weight	300 g
