Panasonic SDR-H80 User Manual

54
LSQT1484
Playback
Editing
1
Deleting scenes/files
[HDD] [SD]
Important:
The deleted scenes/files cannot be restored.
¬Deleting motion picture scenes:
Rotate the mode dial to select .
¬Deleting still picture files:
Rotate the mode dial to select .
¬Select [HDD] or [SD CARD] in
[MEDIA SELECT].
1 Press the button during
playback.
2 When the confirmation message appears
Select [YES], then press the
joystick.
1 Press the button in the
thumbnail display.
2 Select [SELECT] or [ALL] and
press the joystick.
(Only when [ALL] is selected)
≥ All the scenes/files on the HDD or SD card
except the locked scenes/files will be deleted.
Proceed to step 5.
≥ When the date is selected in motion picture
playback, all scenes on the selected date are
deleted.
3 (Only when [SELECT] is selected in step 2)
Select the scene/file to be
deleted, then press the joystick.
The selected scene/file is encircled by a red
frame.
ENTER
≥ To delete an unwanted part of a scene, use the
SPLIT&DELETE function. (l 57)
Deleting scenes/files one at
a time
Deleting multiple scenes/
files
SDR-H90&80GN-LSQT1484_mst.book 54 ページ ２００８年１２月１９日 金曜日 午後４時８分

Panasonic SDR-H80 Specifications

General

Filter size	37 mm
Digital zoom	100 x
Optical zoom	70 x
Image stabilizer	Yes
Focal length range	1.5 - 105 mm
Focal length (35mm film equivalent)	38.5 - 2695 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Interface	USB 2.0, A/V out
Aperture range (F-F)	1.9 - 5.7
Audio recording formats	MPEG1
Power consumption (typical)	3.8 W
Display diagonal	2.7 \
Display resolution	704 x 576 pixels
Video formats supported	MPEG2
Camera shutter speed	1/25 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	1
Product color	Silver
Video recording time	54 h
Compatible memory cards	SD, SDHC
Internal storage capacity	60 GB

Weight and Dimensions

Depth	107 mm
Width	53 mm
Height	67 mm
Weight	300 g
