Panasonic VL-SVN511AZ Installation Guide

10-3. Expanded system example
111
9
Appendix
Lift (up to 3)
* up to 100 floors, up to 20 floors per Lift Controller
#07
* Up to 7 per 4
branches
* Up to 20 (Monitor) x 7 (Distribution Box) x 4 (branches)
Lift Controller (up to 15)
#01
Room Unit (up to 560)
#01
#01
#07
#01
#07
Distribution Box
#06
#04
#07
#05
Repeater Mode
Repeater Mode
#01
#05
#01
#05
#01
#05
Lobby Station
(up to 3)
Distribution
Box (up to 28)
* up to 5 per lift
TV Monitor (1)
(NTSC)
PC
(programming)
SD Card
(Log)
Emergency SLT
(1)
PBX
SLTs (up to 4)
Security Camera
E-Lock
Control Box (1)
Repeater Mode (up to 1 per 1branches)
* You can extend the distance by using the repeater mode.
Extension Box
(up to 18 lobby stations)
