Panasonic VL-SVN511AZ Installation Guide

3-6. Wiring type and length
3
Wiring
Wiring run Wire diameter Max. length
Control box
<--
>
Lobby station
0.65 mm (22 AWG) approx. 100 m
1.2 mm (17 AWG) approx. 200 m
Control box
<--
>
Distribution mode
the farthest distribution box
0.65 mm (22 AWG) approx. 100 m
1.2 mm (17 AWG) approx. 200 m
Control box
<--
>
Repeater mode
the distribution box that is
operating
as a repeater
0.65 mm (22 AWG) approx. 100 m
1.2 mm (17 AWG) approx. 200 m
Repeater mode
the distribution box
that is operating
as a repeater
<--
>
Distribution mode
the farthest distribution box
0.65 mm (22 AWG) approx. 100 m
1.2 mm (17 AWG) approx. 200 m
Distribution box
<--
>
Main monitor
0.65 mm (22 AWG) approx. 100 m
1.2 mm (17 AWG) approx. 200 m
Control box
<--
>
The farthest lift controller
0.65 mm (22 AWG) approx. 100 m
1.2 mm (17 AWG) approx. 200 m
Power supply unit
<--
>
Lobby station
Control box
Distribution box
Lift controller
0.65 mm (22 AWG) approx. 10 m
2 mm (12 AWG) approx. 20 m
Power supply unit
<--
>
AC power source
1.2 mm (17 AWG)
No requirement
2 mm (12 AWG)
Lobby station
<--
>
Electric lock
0.5 mm (24 AWG)
According to specification of
connected device.
1.2 mm (17 AWG)
- Use 2-conductor (solid copper) wiring with a PE (polyethylene)-insulated PVC jacket.
Mid-capacitance, non-shielded cable is recommended.
- A certified power supply wiring has to be used with this equipment. The relevant national installation and/or
equipment regulations shall be considered. A certified power supply wiring not lighter than ordinary polyvinyl
chloride flexible wiring according to IEC 60227 shall be used.
- When connecting an electric lock to the electric lock connection terminal (K-OUT), select a device that meets the following
guidelines.
– N/C or N/O dry closure contact
– 12 V AC/DC, less than 1 A
