Panasonic VL-SVN511AZ Installation Guide

AC
DC power
PS240
Room
Monitor
Lobby Station
VL-V900
7.3 Replace from Cat-3(4wire cable) system
Replace
81
Cat3(0.65mm 4wire)
Distribution Box
VL-V701
Distribution Box
VL-V701
Control Box
VL-V700
RISER
Lobby Station － Control Box : Existing Cable (Cat3)/New Cable
Control Box － Distribution Box : New Cable (Cat-6/1.2mm/0.65mm
Distribution Box/DC Power Supply － Room Monitor : Existing Cable(Cat-5e)+New Cable
Lobby Station
Cat6 Cable
/1.2mm/0.65mm
7
RISER

Panasonic VL-SVN511AZ Specifications

General

Brand	Panasonic
Model	VL-SVN511AZ
Category	Intercom System
Language	English
