Panasonic VL-SVN511AZ Installation Guide

3
Wiring
3-7. Distance / How to use Repeater
Case1
Case3
Case2
Lobby Station
VL-V900
#
1
#
7
#
1
#
7
#
7
Distribution Box
VL-V701
∅ 0.65mm : 100m
∅ 1.20mm : 200m
∅ 0.65mm : 100m
∅ 1.20mm : 200m
∅ 0.65mm : 100m
∅ 1.20mm : 200m
∅ 0.65mm : 100m
∅ 1.20mm : 200m
(usage of
Repeater)
(usage of
Repeater)
Control Box
VL-V700
Distribution Box
VL-V701
Lobby Station
VL-V900
V701
(Repeater Mode)
#
1
Distribution Box
VL-V701
Lobby Station
VL-V900
Control Box
VL-V700
By connecting a VL-V701 (repeater) between the VL-V700 and VL-V701 (#07), the range can be extended by 200 m.
Diameter of cable
Control Box
VL-V700
V701
(Repeater Mode)
The Farthest Monitor
The Farthest Monitor
The Farthest Monitor
The Farthest V701
The Farthest V701
The Farthest V701
33
Total length ∅ 0.65mm : 400m / ∅ 1.20mm : 800m
Extension Box
VL-V703
*V703 is not for range extension.
