Replace photosensitive drum

1. Open the door A.

2. Remove waste toner bottles.

3. Remove the photosensitive drum.

Note:

• Some parts of the printer are easily damaged by static electricity. Touch the metal surface in an area

away from the symbol before touching any part or assembly in an area marked with an electrostatic

sensitive symbol.
