Specifications
3 - 1
3.02 Needle and thread
A For fine materials 60 - 60 70 134 134-35
B For medium-thick materials 40 - 40 100 134 134-35
Needle system
1474E1
Needle system
1471E1
Needle thickness in 1/100 mm
▲
or comparable thicknesses of other thread types
3 Specifications
3.01 PFAFF 1471 E1; 1474 E1
▲
Stitch type:.................................................................................................. 301 (lockstitch)
Handwheel eff. dia.:................................................................................................. 65 mm
Clearance under the roller-presser: ............................................................................ 7 mm
Clearance width: .................................................................................................... 245 mm
Clearance height: ................................................................................................... 115 mm
Post height:............................................................................................................ 180 mm
Dimensions of sewing head:
Length: approx....................................................................................................... 615 mm
Width: approx. ....................................................................................................... 240 mm
Height (above table): approx. ................................................................................. 500 mm
Bedplate:...................................................................................................... 518 x 177 mm
Max. speed: .......................................................................................................4000 spm
◆
Max. stitch length: .................................................................................................. 5,0 mm
Cutting clearance ( on -725/.. ): ....................................................................... 0.9 - 2.5 mm
Cutting speed ( on -725/.. ): .........................................................................2800 cuts/min.
Electrical data:
Operating voltage:.......................................................................... 230 V + 10%, 50/60 Hz
Max. output: ........................................................................................................... 1.2 kVA
Fuse protection: ............................................................................ 1 x 16 A, delayed action
Software: ...................................................................................Version 79-0011 0200/010
Working noise level:
Emission at workplace at n = 2500 min
-1
:..............................................................80 dB(A)
( Noise measurement in accordance with DIN 45 635-48-A-1 )
Net weight of machine head:......................................................................... approx. 61 kg
Gross weight of machine head: ..................................................................... approx. 71 kg
Thread thickness (Nm) max. synthetic
▲
Use
Model
