Preparation
9 Preparation
All regulations and instructions in this Instruction Manual are to be observed!
Special attention is to be paid to the safety regulations!
All preparation work is only to be carried out by appropriately trained personnel.
Before any preparation work is done, the machine is to be disconnected from
the electricity supply by removing the plug from the mains or switching off the
On/Off switch!
9.01 Inserting the needle in the 1471E1
Turn the machine off!
Use only system 134 needles.
● Raise roller-presser 1.
● Swing the eye guard up.
● Pull roller-presser 1 down slightly and
swing it out to the left.
● Loosen screw 2 and insert needle 3 fully
until you feel it stop. The long groove
must be facing to the right.
● Tighten screw 2 and swing the roller-
presser back into position.
Selection of the correct needle depends on the model of the machine as well
as the material and threads being sewn (see chapter 3.02 Needle and thread).
Fig. 9 - 01
1
2
3
9 - 1
