Mounting and commissioning the machine
8 - 1
8 Mounting and commissioning the machine
The machine must only be mounted and commissioned by qualified personnel!
All relevant safety regulations are to be observed!
If the machine is delivered without a table, you must ensure that the frame and
the table top which you intend to use can hold the weight of the machine and
the motor. Be sure that the base is sufficiently sturdy at all times - including
during operation of the machine.
8.01 Mounting
The required electricity supply must be available at the machine’s location.
There must be a level, firm floor and adequate lighting at the machine’s location.
Due to package-related requirements, the table top has been lowered for
transport. A description of how to adjust the height of the table top follows.
8.01.01 Adjusting the table-top height
● Loosen screws 1 and 2 and set the desired table-top height.
● Tighten screw 1 well.
● Adjust the pedal to the desired position and tighten screw 2.
Fig. 8 - 01
1
2
1
