Care and maintenance
12.05 Filling the oil reservoir of the thread lubricator
Check the oil level before every
use.
There must always be oil in the
oil reservoir.
● Fill oil through hole 1 up to marking 2 as
required.
We recommend PFAFF thread
lubrication oil Part no.
280-1-120 217.
Fig. 12 - 06
1
2
12.06 Cleaning the air filter on the control box
Turn the machine off!
● The filter must be cleaned at least once a
week, or more, depending on the
cleanliness of the air.
● Dust which collects on the filter grate 1
is to be removed with a brush.
Never blow the dust off the
filter grate into the machine
housing!
1
Fig. 12 - 07
12 - 4
