PG Drives Technology S70A User Manual

S-DRIVE – OPERATION PG DRIVES TECHNOLOGY
SK76745/10
16
Do not operate the scooter if the battery is nearly discharged. Failure to comply with this
condition may leave the user stranded in an unsafe position, such as in the middle of a road.
PGDT accepts no liability for losses of any kind arising from failure to comply with this condition
8.2.3 TruCharge Indicator Stepping Up
The scooter’s batteries are being charged.
8.2.4 TruCharge Indicator blinks on every 3.5 seconds
The controller has entered Sleep Mode.
8.2.5 TruCharge Indicator Flashing Rapidly
The controller safety circuits have operated and the controller has been prevented from moving the scooter.
This indicates that there is a trip. Please follow this procedure:
 Switch off the scooter.
 Make sure that all connectors on the scooter are mated securely.
 Check the condition of the battery.
 If you can’t find the problem, try using the self-help guide in section 8.3.
 Switch the scooter on again and try to drive. If the safety circuits operate again, switch off and do not try to use
the scooter.
 Contact your service agent.
If a system trip occurs you can find out what has happened by counting the number of bars that are flashing on the TruCharge
Indicator. Refer to section 8.3.
8.3 Self-Help Guide
Below is a list of self-help actions. Try to use the following table before you contact your service agent. Go to the number in the list
that matches the number of flashing bars and follow the instructions.
